Roland DGXPRESS UG-642 UV Printer Cutter

UG-642 - UV Printer/Cutters

The Roland DGXPRESS UG-642 is a powerful UV printer/cutter engineered for high-speed, high-quality production. Whether you’re printing labels, signage, decals, or custom packaging, the UG-642 offers unmatched flexibility with CMYK+White+Gloss UV inks, delivering stunning results on a wide range of media.

** VIEW AND DOWNLOAD THE BROCHURE **

Get Pricing Download Brochure

Its integrated cutting system allows seamless print-and-cut workflows, eliminating the need for additional equipment. With fast-drying UV inks and instant curing, you can move straight from printing to finishing—perfect for quick-turnaround jobs.

Designed for growing businesses and professionals looking to expand their offerings, the UG-642 combines productivity, precision, and print durability in one compact solution.

Print & Cut in One: Integrated contour cutting boosts productivity.
CMYK + White + Gloss UV Inks: Add texture, highlights, and opacity to enhance your graphics.
Instant Curing: UV inks dry instantly for faster finishing and delivery.
Versatile Media Support: Print on vinyl, PET, film, paper, synthetic labels, and more.
High-Speed Output: Ideal for short-run production and custom jobs.
Roland DG Reliability: Built for consistent performance and long-term use.

Printing method			Piezo ink-jet method
Media	Width		335 to 1625 mm (13.2 to 64 in.)
	Thickness		Max. 1.0 mm (39.3 mil) with liner, for printing Max. 0.4 mm (15.7 mil) with liner and 0.22 mm (8.6 mil) without liner, for cutting
	Roll outer diameter		Max. 250 mm (9.8 in.)
	Roll weight		Max. 45 kg (99 lb.)
	Core diameter		76.2 mm (3 in.) or 50.8 mm (2 in.)
Printing / cutting width¹			Max. 1600 mm (62.9 in.)
Ink	Type		UV-ink (D-UAP) 750ml pouch
	Colours		Six Colours (Cyan, Magenta, Yellow, Black, Gloss, and White) Four colours (Cyan, Magenta, Yellow, and Black)
Ink curing unit			Built-in UV-LED lamp
Print resolution (dots per inch)			Max. 1200 dpi
Cutting speed			10 to 300 mm/s (0.39 to 11.8 in./s)
Blade force²			30 to 500 gf
Blade	Type		Roland CAMM-1 series blade
	Offset		0 to 1.500 mm (0 to 59 mil)
Software resolution (when cutting)			0.025 mm/step (0.98 mil/step)
Media heating system³			Front heater set temperature: 30 to 55 ℃ (86 to 131 °F)
Connectivity			Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function			Automatic sleep feature
Power requirements			100-120/220-240 Va.c. 50/60 Hz 6.5/3.2 A
Power consumption	During operation		Approx. 800 W
	Sleep mode		Approx. 85 W
Acoustic noise level	During operation		63 dB (A) or less
	During standby		58 dB (A) or less
Dimensions (with stand)			2902 mm x 748 mm x 1412 mm (114.3 in. x 29.5 in. x 55.6 in.)
Weight (with stand)			209 kg (461 lb.)
Environment	During operation⁴	Temperature : 20 to 32 ℃ (68 to 89.6 °F), Humidity: 35 to 80 % RH (no condensation)
	Not operating	Temperature : 5 to 40 ℃ (41 to 104 °F), Humidity: 20 to 80 % RH (no condensation)
