TrueVIS AP-640 Latex Printer | High-Performance Large Format Printer

AP640

The TrueVIS AP-640 Large Format Latex Printer is a cutting-edge solution for print professionals who demand excellence. Engineered for high-performance output, the AP-640 delivers vivid, high-resolution prints across a wide variety of media, thanks to Roland DG’s advanced latex ink technology. Enjoy superior color consistency, stable long-run printing, and lower maintenance costs, all backed by Roland's trusted innovation. Whether you’re in signage, décor, or packaging, this latex printer is built to help you work faster, smarter, and more sustainably—without compromising quality.

** VIEW AND DOWNLOAD THE BROCHURE **

Get Pricing Download Brochure

Next-Level Consistency That Keeps You Ahead

Deliver consistent, high-quality results with the TrueVIS AP-640 Latex Printer. Featuring Roland DG’s advanced media feed and take-up system, the AP-640 ensures exceptional color consistency and precise registration throughout long production runs. Say goodbye to print drift and rework — this printer is built for accuracy and stability from the first print to the last.

Whether you're handling high-volume signage, wraps, or décor applications, the AP-640 gives you the reliability and precision your business needs — and the quality your customers will appreciate.

? Vibrant Colors
Experience natural beauty and unmatched vividness never seen before in a latex printer.

? Consistent Print Quality
Delivers stable, precise, and accurate results over extended print runs, ensuring top-tier output every time.

? Reliable & Fast Performance
Produce high-quality prints with speed and reliability — ideal for short deadlines and high-demand jobs.

? Lower Operating Costs
Maximize productivity while reducing ink and energy costs, thanks to Roland DG’s advanced technology.

? Minimal Maintenance
Enjoy dependable operation with minimal downtime and low maintenance requirements.

? User-Friendly & Intuitive Design
Equipped with smart, easy-to-use software and an ergonomic design for a smoother printing experience.

		AP-640
Printing method		Piezo ink-jet method
Media	Width	10.2 to 64 in. (259 to 1,625 mm)
	Thickness	Max. 0.039 in. (1.0 mm) with liner
	Roll outer diameter	Max. 9.8 in. (250 mm)
	Roll weight	Max. 99 lb. (45 kg)
	Core diameter	3 in. (76.2 mm) or 2 in. (50.8 mm)
*Printing width (1)**		Max. 63.5 in. (1,615 mm)
Ink	Type	Resin/Latex ink 700 ml pouch
Ink	Colors	Four colors (cyan, magenta, yellow, and black) and optimizer
Printing resolution (dots per inch)		Max. 1200 dpi
*Ink drying system (2)**		Print heater set temperature: 77 to 113°F (25 to 45°C)
*Ink drying system (2)**		Dryer set temperature: 158 to 230°F (70 to 110°C)
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function		Automatic sleep feature
Rated Input		Printer: 200-240 Va.c. 50/60 Hz 3 A
		Dryer 1: 200-240 Va.c. 50/60 Hz 10 A
		Dryer 2: 200-240 Va.c. 50/60 Hz 10 A
Power consumption	During operation	Approx. 4,000 W
Power consumption	Sleep mode	Approx. 65 W
Acoustic noise level	During operation	69 dB (A) or less
Acoustic noise level	During standby	53 dB (A) or less
Dimensions (Width x Depth x Height)		113.7 in. × 33 in. × 61.1 in. (2,886 mm × 836 mm × 1,550 mm)
Weight (with stand)		587 lb. (266 kg)
*Environment (3)**	During operation	Temperature: 68 to 86 °F (20 to 30 °C),
	During operation	Humidity: 20 to 80 %RH (no condensation)
	Recommended Environment	Temperature: 68 to 77 °F (20 to 25 °C),
	Recommended Environment	Humidity: 40 to 60 %RH (no condensation)
	Not operating	Temperature: 41 to 104 °F (5 to 40 °C),
	Not operating	Humidity: 20 to 80 %RH (no condensation)
Included items		Dedicated stand, power cords, dryers, media take-up unit, media holders, separating knife, replacement blade, cleaning liquid bottle for maintenance, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect), etc.
