| Printing Method |
Piezo ink-jet method |
| Attachable objects to be printed on |
Width: Max. 25.1 in. (640 mm)
Length: Max. 19.2 in. (488 mm)
Thickness: Max. 8 in. (204 mm)
Weight: Max. 17.6 lb. (8 kg) (With vacuum table: max. 8.8 lb. / 4 kg) |
Width: Max. 19.2 in. (488 mm)
Length: Max. 13.1 in. (335 mm)
Thickness: Max. 8 in. (204 mm)
Weight: Max. 8.8 lb. (4 kg) |
| Printing width/length |
Max. 24 in. × 18 in. (610 mm × 458 mm) |
Max. 18 in. × 12 in. (458 mm × 305 mm) |
| Ink |
Type: ECO-UV (EUV5) 750 ml pouch, UV-ink (EUV-A) 750 ml pouch, UV-ink (E-BOND) 750 ml pouch |
| Colors |
ECO-UV (EUCSP):
- 8 colors (Cyan, Magenta, Yellow, Black, Gloss, White, Orange, Red)
- 7 colors (Cyan, Magenta, Yellow, Black, White, Orange, Red and Primer)
- 7 colors (Cyan, Magenta, Yellow, Black, Gloss, White, x2 and Primer)
- 6 colors (Cyan, Magenta, Yellow, Black, Gloss, White x2)
- 6 colors (Cyan, Magenta, Yellow, Black, Gloss x2, White x2)
- 4 colors (Cyan, Magenta, Yellow, Black x2)
UV-Ink (EUV-A):
- 6 colors (Cyan, Magenta, Yellow, Black, Gloss x2, White x2)
UV-Ink (E-BOND):
- 6 colors (Cyan, Magenta, Yellow, Black, Gloss, White) |
| Ink-curing unit |
Built-in UV-LED lamp |
| Printing resolution (dpi) |
Max. 1200 dpi |
| Connectivity |
Ethernet (100BASE-TX/1000BASE-T, automatic switching) |
| Power-saving function |
Automatic sleep feature |
| Power requirements |
100–240 Vac, 50/60 Hz 3.5A |
| Power consumption |
During operation: Approx. 290 W
Sleep mode: Approx. 70 W |
During operation: Approx. 290 W
Sleep mode: Approx. 70 W |
| Acoustic noise level |
60 dB (A) or less |
60 dB (A) or less |
| Dimensions (W × D × H) |
63.1 in. × 49.9 in. × 30.0 in. (1601 mm × 1267 mm × 760 mm) |
57.1 in. × 37.9 in. × 30.0 in. (1449 mm × 961 mm × 760 mm) |
| Weight |
465.1 lb. (211 kg) |
383.6 lb. (174 kg) |
| Environment |
During operation: 68 to 89.6 °F (20 to 32 °C), Humidity: 35 to 80 %RH (no condensation)
Not operating: 41 to 104 °F (5 to 40 °C), Humidity: 20 to 80 %RH (no condensation) |
| Included items |
Power cord, cleaning liquid, drain bottle, User's Manual, software (VersaWorks, Roland DG Connect) etc. |
